Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard

Name: Early Streamer Emission Ese Lightning Rod On Buildings NF C 17102 Standard
Brand: TSTLP
Price: 1 USD

Quality Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard for sale

Brand Name : TSTLP

Model Number : SMT-ESE30

Certification : Patent / CE

Place of Origin : Guangdong, P.R.C.

MOQ : 4pc (1st order< 4pc is OK)

Price : Negotiable if good quantity

Packaging Details : 23x23x45cm colorful box/pc, and 4 pcs in 49x50x50cm carton

Delivery Time : Around 6 working days upon receipt of payment

Payment Terms : Full TT / LC / Western Union / MoneyGram / WeChat Transfer / Alipay / Wanda Money Transfer / Cash in advance

Supply Ability : 1,000 sets/month

Name : Early Streamer Emission Lightning Rod

Efficiency : 30 microsecond in advance

Iimp withstanding test : 100kA Iimp required

lightning current withstanding : 200kA

Standards : NF C 17-102:2011

Weight : 3.0kg

Max Rp : 90m

HS Code : 85354000.00

Contact Now

TSTLP Early Streamer Emission Lightning Rod On Buildings As Per NF C 17-102 Standard

Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard

TSTLP Early Streamer Emission Lightning Rod's Working Principle

Lower electrodes of TSTLP early streamer emission lightning rod gather energy from naturally occurring ambient electrical fields that increase as much as ten thousand volts per meter as the storm approaches.
TSTLP early streamer emission lightning rod collects the electrical energy and stores in capacitors inside the TSTLP ESE. Just before a lightning strike the atmospheric electrical field increases rapidly,activating the patented triggering device.
TSTLP early streamer emission lightning rod’s trigger releases the stored energy in the capacitors through the upper electrodes at the tip of the air terminal and initiates an upward leader at the optimum moment.
Upward leader that TSTLP early streamer emission lightning rod produces connects with the downward leader and the result is a lightning strike that directed safely to ground through the air terminal, downleads, and grounding system.

Technical Data

TSTLP ESE lightning rod models	SMT-ESE30
Patent No.	2013300191363
Efficiency (ΔT)	30μs
Standard Deviation ESE / Single Rod σ	σESE < 0.6 σPTS
Lightning current withstanding test Iimp	100kA (normative test at 10/350μs waveform as standard requires)
Lightning current withstanding Iimp	≥ 200kA (10/350)
Capacity against wind speed	≥40m/s
Dimension(Length)	418 mm
Approx net weight	3.0kg
Enclosure material	Superior Quality Stainless Steel
Test Standards	NF C 17-102_2011 Annexe C
	UNE 21.186:2011 Paragraph C
	IEC 60060-1:2010 Part 1
	EN 60060-1:2010
	GB/T T16927.1-2011 Part 1;

SMT-ESE30 early streamer emission lightning rod MECHANICAL SPECS

Fixed on elevation pole		M20 Thread
Down conductor connection		Specific tape/cable clamp
PACKING IN DETAIL
Dimensions		230230450 mm box/pc, 4pcs in 480500500mm carton
Packing Contents		TSTLP^® E.S.E. early streamer emission lightning rod Head, Nut, Hex key;
Approx GT (kg)		4
Environmental sustainability		100% recyclable

Radius Protection Table of TSTLP SMT-ESE30 Early Streamer Emission Lightning Rod

Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard

TSTLP Early Streamer Emission Lightning Rods On Building Protection

Installation procedure for TSTLP ESE Lightning Rod is governed by latest French standard NF C 17-102 and follows a series of simple rules catering for all types of structure;(Referring to installation stated in French standard NF C 17-102_2011)

Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard

Part stock of TSTLP Early Streamer Emission Ese Lightning Rods

Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard

Installation Photos

Early Streamer Emission Ese Lightning Rod On Buildings NF C 17-102 Standard

Download PDF 2020 TSTLP Early Streamer Emission Lightning Rod Catalog @ https://drive.google.com/file/d/1kEW-pWdJdlArVgfrHutq62k9HsVNcHq-/view?usp=sharing

PDF Datasheet DOWNLOAD - TSTLP SMT-ESE30.pdf
